Dual VHM-25 Channel Mount Assembly – Weight Range Per Arm: 7 to 20 lbs/3.2 to 9.1 kg

• Maximum flat panel width: 20” / 50.8 cm each
• Small profile – space saving design
• 75/100 mm VESA compatible
• Independent tilt/swivel adjustment
• Portrait/landscape adjustment
• 12” / 30.5 cm height adjustment
• Smooth continuous surface with minimal seams for easy cleaning
• Product Weight: 9.6 lbs / 4.3 kg

Note: If using monitor handles with a flat panel display that has a 100mm hole pattern, FLP-0002-17 is required.

GE Corometrics 170 Series Adapter Plate

• Adapter plate secures the GE Corometrics 170 to the Fetal Monitoring mount

VHRC Counterweight

• 10 lb/4.5 kg Counterweight
• Add-on kit for VHRC/RC
• Requires RST-0007-22

GE Mini Telemetry Receiver Rear Column Mount

• 12″/30.5 cm M Series Arm
• Swivel only slide-in mount
• Rear column mounting adapter
• Note: GE Adapter plate required: GE P/N: 2051641-001

GE Mini Telemetry Receiver Adapter Plate

Channel Mount Medical-Grade Power Strip with 4 Hospital-Grade Outlets and 15’ Cord (UL 1363A Rating)

Channel Mount Medical-Grade Power Strip with 6 Hospital-Grade Outlets and 15’ Cord (UL 1363A Rating)

Channel Mount Medical-Grade Power Strip with 4 Hospital-Grade Outlets and 10’ Coiled Cord (UL 1363A Rating)

VHRC Rear Column Accessory Track Mounting Adapter

• Adapter plate for rear column mounting

Note: Two (2) required for this mounting configuration

Channel Mount for 1.5 to 3"/3.8 to 7.6 cm wide CPU

• Max. load: 25 lb / 11.3 kg
• Max. height: 14″ / 35.6 cm
• Max. depth: 14″ / 35.6 cm
• Weight: 4.5 lb / 2 kg

Channel Mount for 3 to 4.5"/7.6 to 11.4 cm wide CPU

• Max. load: 25 lb / 11.3 kg
• Max. height: 14″ / 35.6 cm
• Max. depth: 14″ / 35.6 cm
• Weight: 5 lb / 2.3 kg

Channel Mount for 4.5 to 7"/11.4 to 17.8 cm wide CPU

• Max. load: 40 lb / 18.2 kg
• Max. height: 18″ / 45.7 cm
• Max. depth: 18″ / 45.7 cm
• Weight: 16 lb / 7.3 kg
• Note: Requires a channel longer than 7″ / 17.8 cm to accommodate two (2) slides

Channel Mount for 7 to 9.5"/17.8 to 24.1 cm wide CPU

• Max. load: 40 lb / 18.2 kg
• Max. height: 18″ / 45.7 cm
• Max. depth: 18″ / 45.7 cm
• Weight: 18 lb / 8.2 kg
• Note: Requires a channel longer than 7″ / 17.8 cm
• Note: For rear VHRC/RC configurations, requires two (2) Rear Cleats

UPS Mount for VHRC/RC

• UPS rear mount for VHRC/RC carts
• Maximum UPS: 5.75″/14.6cm W x 18″/45.7cm L x 7″/17.8cm T
• Velcro straps
• Maximum weight: 30lbs/13.6kg

Caution: Do not use with UPS devices with dimensions larger than the tray or heavier than 30lbs/13.6kg.
